Instruction Manual — C1 USB-C Wired Mouse

This manual covers setup, operation, and features for the Satechi C1 USB-C Wired Mouse (Model: ST-AWUCMM).

📄 Download User Manual — C1 USB-C Wired Mouse · PDF · 716 KB

In the Box

C1 USB-C Wired Mouse, User Manual.

Specifications

Model: ST-AWUCMM
Dimensions: 4.37" x 2.25" x 1.25"
Cable Length: 1.5 meters
Weight: 3.6 oz
Connector: USB-C (wired)
DPI: 800 / 1200 / 2400 / 3200

Important: Requires a device with a USB-C port.

Parts Reference

1. USB-C Connector — The built-in USB-C cable that connects to your device.
2. Left Button — Primary click button.
3. Right Button — Secondary click / right-click button.
4. Scroll Wheel — Scroll up and down to navigate content.
5. Optical Sensor — Located on the bottom of the mouse; tracks movement.
6. LED Indicator (DPI Level) — Located on the bottom of the mouse; shows the current DPI setting.

Connecting to Your Device

Plug the USB-C cable into a USB-C port on your Mac or PC. The C1 Mouse is plug-and-play — it will be detected automatically with no drivers required.

Note: If your device only has USB-A ports, you will need a USB-A to USB-C adapter (sold separately).

Adjusting DPI

Press the DPI Adjustment Button (located on the bottom of the mouse) to cycle through four DPI levels. The LED Indicator on the bottom of the mouse changes color to show the current DPI setting:

Red LED — 800 DPI
Blue LED — 1200 DPI (default)
Green LED — 2400 DPI
Purple LED — 3200 DPI

Frequently Asked Questions

Does this mouse require any drivers or software?
No. The C1 Mouse is plug-and-play and works with macOS, Windows, and ChromeOS without any drivers or software installation.

What if my device only has USB-A ports?
You can use a USB-A to USB-C adapter (not included) to connect the C1 Mouse to a USB-A port.

How do I change the DPI setting?
Press the DPI Adjustment Button on the bottom of the mouse to cycle through the four DPI levels: 800, 1200, 2400, and 3200. The LED color will change to indicate the current setting.

What is the default DPI setting?
The default DPI setting is 1200, indicated by the Blue LED on the bottom of the mouse.

Safety Instructions

Warning: Fire, electric shock, or damage to the mouse could occur if the following instructions are not obeyed.

1. Do not expose to extreme heat or direct sunlight for extended periods.
2. Do not drop or subject the mouse to strong impacts.
3. Keep away from liquids and moisture.
4. Do not place heavy objects on the cable.

Need Help?

Contact Satechi Support at support.satechi.com or email support@satechi.com.
Phone: +1 858 268 1800 | Website: www.satechi.com
