This User Manual covers all features and setup for the Satechi C1 USB-C Wired Mouse (ST-AWUCMM), a wired mouse with adjustable DPI settings.

What's In The Box

C1 USB-C Wired Mouse, User Manual.

Specifications

Model: ST-AWUCMM
Connection Type: USB-C (wired)
DPI Levels: 800 / 1200 / 2400 / 3200 DPI

Functions

1. USB-C Connector — The built-in USB-C cable that connects to your device.
2. Left Button — Primary click button.
3. Right Button — Secondary click / right-click button.
4. DPI Adjustment Button — Press to cycle through the four DPI levels.
5. Scroll Wheel — Scroll up and down to navigate content.
6. Optical Sensor — Located on the bottom of the mouse; tracks movement.
7. LED Indicator (DPI Level) — Located on the bottom of the mouse; shows the current DPI setting.

Setup

Plug & Play

Plug into a USB-C port and the mouse will be detected by the device automatically.

LED Indicators

Press the DPI Adjustment Button on the bottom of the mouse to cycle through the four DPI levels. The LED Indicator changes color to show the current DPI setting:

Red LED — 800 DPI
Blue LED — 1200 DPI (Default)
Green LED — 2400 DPI
Purple LED — 3200 DPI
