Instruction Manual — Aluminum Type-C to HDMI Adapter

This manual covers setup and features for the Satechi Aluminum Type-C to HDMI Adapter (Models: ST-TC4KHAS / ST-TC4KHAG / ST-TC4KHAM / ST-TC4KHAR).

📄 Download User Manual — Aluminum Type-C to HDMI Adapter · PDF · 1.4 MB

In the Box

Aluminum Type-C to HDMI Adapter, User Manual.

Specifications

Models: ST-TC4KHAS (Silver) / ST-TC4KHAG (Gold) / ST-TC4KHAM (Space Gray) / ST-TC4KHAR (Rose Gold)
Dimensions: 8 × 0.88 × 0.25 in (203 × 22 × 6 mm)
Weight: 19 g
Connector Type: USB-C to HDMI
Maximum Resolution: Up to 4K/60Hz
Construction: Aluminum housing

Parts Reference

1. HDMI Connector — Full-size HDMI connector at the display end of the adapter. Connect to the HDMI port on your external monitor, TV, or projector. Supports video output up to 4K/60Hz.
2. LED Indicator — Illuminates when the adapter is connected and active, confirming a live display connection.
3. USB-C Connector — USB-C connector at the device end of the adapter. Plug into the USB-C or Thunderbolt port on your laptop or tablet. The host USB-C port must support DisplayPort Alt Mode (DP Alt Mode).

Setup

The Aluminum Type-C to HDMI Adapter is plug-and-play — no drivers required on macOS or Windows.

Step 1: Connect the USB-C end (Port 3) to the USB-C or Thunderbolt port on your computer or tablet. Confirm your USB-C port supports DisplayPort Alt Mode.
Step 2: Connect the HDMI end (Port 1) to the HDMI port on your external monitor, TV, or projector.
Step 3: On your display, switch the input source to HDMI. The LED indicator (Port 2) will illuminate to confirm an active connection.

Important Notes

Host USB-C port must support DP Alt Mode: This adapter requires DisplayPort Alternate Mode (DP Alt Mode) on the host USB-C port. Most MacBooks, iPad Pros, and modern Windows laptops with USB-C or Thunderbolt ports support this. Check your device specifications to confirm before purchasing.

Maximum resolution is 4K/60Hz: This adapter supports video output up to 4K resolution at 60Hz. It does not support 8K output or high-refresh-rate modes beyond 60Hz at 4K.

Available in four colors: Choose between Silver (ST-TC4KHAS), Gold (ST-TC4KHAG), Space Gray (ST-TC4KHAM), and Rose Gold (ST-TC4KHAR) to match your device.

Frequently Asked Questions

What resolution does this adapter support?
This adapter supports video output up to 4K/60Hz on compatible displays and computers.

Does my USB-C port support DP Alt Mode?
Most USB-C and Thunderbolt ports on MacBooks, iPad Pros, and modern Windows laptops support DP Alt Mode. Check your device's technical specifications. Not all USB-C ports support video output — some are data-only.

Does this adapter support audio?
Yes. HDMI carries both video and audio signals. When connected, audio will route to the external display or TV via HDMI.

Is this compatible with the iPad Pro?
Yes. iPad Pro models with USB-C support HDMI video output via DP Alt Mode. Connect the adapter's USB-C end to your iPad Pro and the HDMI end to your display.

Does this adapter work in mirror or extended mode?
Yes. macOS and Windows both support mirror and extended display modes when using this adapter. Configure your preferred mode in your system's display settings.

Safety Instructions

Warning: Fire, electric shock, or damage could occur if the following instructions are not obeyed.

1. Do not bend or kink the cable portion of the adapter sharply.
2. Keep away from liquids and moisture.
3. Do not use if the adapter or connectors are damaged.
4. Do not force connectors into ports — ensure correct alignment before inserting.
