This User Manual covers functions, power, pairing, charging, and LED indicators for the Satechi Bluetooth Extended Keypad.

Specifications

Connectivity: Bluetooth
Charging: USB-C Charging Port (USB-C to USB-A Charging Cable included)

Functions

1. Power & Pairing LED Indicator: Blue LED that shows Pairing Mode, paired status, and Battery Low.
2. USB-C Charging Port: Connect the included USB-C to USB-A Charging Cable here to charge the keypad.
3. Charging Indicator: Red LED that shows charging status.
4. Bluetooth Pairing Button: Press and hold for 5 seconds to enter Pairing Mode.
5. On/Off Switch: Slide to turn the keypad on or off.

Note: The keypad layout function is based on iOS and macOS default settings. The output might differ for different operating systems.

Setup

Powering On / Off

Slide the On/Off Switch to ON or OFF to turn the keypad on or off.

Pairing (Bluetooth)

1. Press and hold the Bluetooth Pairing Button for 5 seconds. The blue LED blinks fast, indicating Pairing Mode.
2. Pair the keypad with your device over Bluetooth.
3. Once paired, the blue light turns off.

Charging

A USB-C to USB-A Charging Cable is included. Connect the USB-C end to the keypad's USB-C Charging Port and the USB-A end to a USB-A port. Charging takes 2 to 3 hours. The red LED is on while charging and turns off when the keypad is fully charged.

Note: The keypad will only charge via the USB-C to USB-A Charging Cable. It will not charge with a USB-C to USB-C cable.

Battery Life

Note: To preserve battery life, the keypad will enter sleep mode automatically after about 1 hour of inactivity.

LED Indicators

Blue LED blinking fast: Pairing Mode.
Blue LED: Battery Low.
Blue light turns off: Paired.
Red LED: Charging.
Red light turns off: Fully Charged.

Important

Keep away from water and other liquids.

Certifications

FCC, CE, WEEE, ISED (IC: 24917-STXLABK), EAC
