Instruction Manual — USB-C Pro Hub Mini Adapter

This manual covers setup and features for the Satechi USB-C Pro Hub Mini Adapter (Model: ST-UCPHMIM / ST-UCPHMIS).

📄 Download User Manual — USB-C Pro Hub Mini Adapter · PDF · 1.6 MB

In the Box

USB-C Pro Hub Mini Adapter, User Manual.

Specifications

Model: ST-UCPHMIM (Space Gray) / ST-UCPHMIS (Silver)
Dimensions: 3.97" x 1.5" x 0.47"
Connector: Dual USB-C (with adjustable headphone jack)

Ports & Speeds:
1× USB4 — up to 96W charging, up to 6K 60Hz display output, up to 40 Gbps data transfer
2× USB-A 3.0 Gen 1 — up to 5 Gbps data (does not support charging or CD drives)
1× Gigabit Ethernet
1× USB-C data port — up to 5 Gbps
1× 3.5mm audio jack

Parts Reference

1. Dual USB-C Connectors — The two USB-C connectors that attach the hub to your laptop's USB-C ports.
2. Audio Jack Connector — The adjustable audio jack connector arm.
3. Audio Jack Port — 3.5mm audio jack for headphones or speakers.
4. USB4 Port — Supports up to 96W charging pass-through, up to 6K 60Hz display output, and up to 40 Gbps data transfer.
5. Ethernet Port — Gigabit Ethernet for wired network connectivity.
6. 2× USB-A 3.1 Gen 1 Ports — Two USB-A ports for data transfer up to 5 Gbps. Does not support charging or CD drives.
7. LED Indicator — Lights up when the hub is connected and powered.
8. USB-C Data Port — USB-C port for data transfer up to 5 Gbps.

Setup

The Pro Hub Mini is plug-and-play — no drivers or software required.

Step 1: Plug the Dual USB-C Connectors into the USB-C ports on your laptop.
Step 2: Connect your devices to the hub's ports.

Note: The audio jack connector arm is adjustable to accommodate laptops of different thicknesses.

Important Notes

USB device current limit: Connected USB devices should not exceed an input current of 900mA per port.

USB-A ports do not support charging: The 2× USB-A ports are for data transfer only and cannot charge connected devices.

USB4 port display output: For 6K 60Hz display output, use a compatible USB4 or Thunderbolt 4 cable and display.

Frequently Asked Questions

How do I connect the Pro Hub Mini to my Mac?
Simply plug the dual USB-C connectors into the USB-C ports on your Mac. The hub is plug-and-play with no drivers required.

Can I charge devices through the USB-A ports?
No. The USB-A ports are for data transfer only (up to 5 Gbps) and do not support charging connected devices.

What is the maximum wattage for USB-C charging pass-through?
The USB4 port supports up to 96W charging pass-through.

Does the Ethernet port support Gigabit speeds?
Yes. The Ethernet port supports Gigabit (1 Gbps) speeds.

Safety Instructions

Warning: Fire, electric shock, or damage could occur if the following instructions are not obeyed.

1. Do not expose to extreme heat or direct sunlight for extended periods.
2. Do not drop or subject the hub to strong impacts.
3. Keep away from liquids and moisture.
4. Do not exceed 900mA input current per USB port.

Need Help?

Contact Satechi Support at support.satechi.com or email support@satechi.com.
Phone: +1 858 268 1800 | Website: www.satechi.com
