Instruction Manual — USB-C Pro Hub Max Adapter

This manual covers setup and features for the Satechi USB-C Pro Hub Max Adapter (Model: ST-UCPHMXM / ST-UCPHMXS).

📄 Download User Manual — USB-C Pro Hub Max Adapter · PDF · 1.7 MB

In the Box

USB-C Pro Hub Max Adapter, User Manual.

Specifications

Model: ST-UCPHMXM (Space Gray) / ST-UCPHMXS (Silver)
Dimensions: 4.86" x 1.22" x 0.46" (75 x 135 mm)
Weight: 1.94 oz
Connector: Dual USB-C (with adjustable headphone jack)

Ports & Speeds:
1× USB4 — up to 96W charging, up to 6K 60Hz display output, up to 40 Gbps data transfer
1× HDMI — up to 4K 60Hz video output
1× USB-A 3.0 — up to 5 Gbps data (does not support charging or CD drives)
1× SD + Micro SD card slots
1× Gigabit Ethernet (LAN 10/100/1000)
1× USB-C data port — up to 5 Gbps
1× 3.5mm audio jack

Parts Reference

1. Dual USB-C Connectors — The two USB-C connectors that attach the hub to your laptop's USB-C ports.
2. Audio Jack Connector — Adjustable connector arm for the 3.5mm audio jack.
3. Audio Jack Port — 3.5mm audio jack for headphones or speakers.
4. USB-C Data Port — USB-C data transfer port, up to 5 Gbps.
5. Ethernet Port — Gigabit Ethernet (LAN 10/100/1000) for wired network connectivity.
6. SD & Micro SD Card Slots — Dual card readers for SD and Micro SD cards.
7. USB-A 3.0 Port — USB-A data port, up to 5 Gbps. Does not support charging or CD drives.
8. 4K@60Hz HDMI Video Port — HDMI port supporting up to 4K 60Hz video output.
9. LED Indicator — Lights up when the hub is connected and powered.
10. USB4 Port — Supports up to 96W charging pass-through, 6K 60Hz display output, and 40 Gbps data transfer.

Setup

The Pro Hub Max is plug-and-play — no drivers or software required.

Step 1: Plug the Dual USB-C Connectors into the USB-C ports on your laptop.
Step 2: Connect your devices to the hub's ports.

Note: The audio jack connector arm is adjustable to accommodate laptops of different thicknesses.

Important Notes

USB device current limit: Connected USB devices should not exceed an input current of 900mA per port.

USB-A port does not support charging: The USB-A port is for data transfer only and cannot charge connected devices.

Dual video output: The USB4 port and HDMI port can be used simultaneously for dual display setups. USB4 supports up to 6K 60Hz; HDMI supports up to 4K 60Hz.

Frequently Asked Questions

How do I connect the Pro Hub Max to my Mac?
Plug the dual USB-C connectors into the USB-C ports on your Mac. The hub is plug-and-play with no drivers required.

Can I charge devices through the USB-A port?
No. The USB-A port is for data transfer only (up to 5 Gbps) and does not support charging.

What is the maximum charging wattage on the USB4 port?
The USB4 port supports up to 96W charging pass-through.

Can I use both the HDMI and USB4 ports for dual display output?
Yes. You can connect two displays simultaneously — one via HDMI (up to 4K 60Hz) and one via USB4 (up to 6K 60Hz).

Safety Instructions

Warning: Fire, electric shock, or damage could occur if the following instructions are not obeyed.

1. Do not expose to extreme heat or direct sunlight for extended periods.
2. Do not drop or subject the hub to strong impacts.
3. Keep away from liquids and moisture.
4. Do not exceed 900mA input current per USB port.

Need Help?

Contact Satechi Support at support.satechi.com or email support@satechi.com.
Phone: +1 858 268 1800 | Website: www.satechi.com
